Fixed Vacuum Capacitors for Sale

Penta Labs manufactures OEM equivilant replacement fixed vacuum capacitors for Comet, Jennings, GLVAC and Greenstone.

Fixed Vacuum Capacitors List:

Model # (Greenstone USA / Jennings / Comet) Capacitance (Pf) Voltage KV (Peak Testing) Voltage KV (Peak Working) Max. RMS Amps Length (mm/inch) Diameter (mm/inch)
CKY-1 / CKY-1-0030S 1 30.0 18 8 83.5/3.28 19.3/0.76
CKY-2 / CKY-2-0030S 2 30.0 18 9 83.5/3.28 19.3/0.76
CKY-3 / CKY-3-0030S 3 30.0 18 10 83.5/3.28 19.3/0.76
CKY-5 / CKY-5-0030S 5 30.0 18 12 83.5/3.28 19.3/0.76
CKT-6-0035 6 +/-10% 35.0 25 47 165.1/6.5 58.9/2.32
VC1C-10-0015M / C1C 10E 10 +/-5% 15.0 9 7 62/2.44 48/1.89
CFC-12 / CKT-12-0035 / CF3C-12G 12 +/-10% 35.0 25 52 165.1/6.5 58.9/2.32
VC1C-25-0015M / C1C 25E 25 +/-5% 15.0 9 16 62/2.44 48/1.89
CKT1-25-0025 25 +/-5% 25.0 15 50 114/4.5 68/2.68
CKT-25-0035 / CF3C-25H 25 +/-10% 35.0 25 67 165.1/6.5 58.9/2.32
VC1C-50-0015M / C1C 50E 50 +/-5% 15.0 9 32 62/2.44 48/1.89
VC2C-50 / MC2C 50E 50 +/-5% 30/25/20 18/15/12 108 73/2.87 48/1.89
CFHD-50-60S / CKT1-50-0025 50 +/-5% 25.0 15 60 114/4.5 68/2.68
CKT-50-0035 / CF3C-50G 50 +/-10% 35.0 25 77 165.1/6.5 58.9/2.32
CF2-60-0015 / CF1-60-0015 60 +/-5% 15.0 9 40 62.3/2.45 44.5/1.75
CF2-70-0015 / CF1-70-0015 70 +/-5% 15.0 9 45 62.3/2.45 44.5/1.75
VC1C-70-0015M / C1C 70E 70 +/-5% 15.0 9 45 62/2.44 48/1.89
CKT1-75-0025 75 +/-5% 25.0 15 65 114/4.5 68/2.68
CKT-75-0035 / CF3C-75E 75 +/-5% 35.0 25 82 165.1/6.5 58.9/2.32
CF2-80-0015 / CF1-80-0015 80 +/-5% 15.0 9 76 62.3/2.45 44.5/1.75
VC1C-80-0015M / C1C 80B & E 80 +/-5% 15.0 9 51 62/2.44 48/1.89
CF2-90-0015 / CF1-90-0015 90 +/-5% 15.0 9 62 62.3/2.45 44.5/1.75
VC1C-90-0015M / C1C 90E 90 +/-5% 15.0 9 62 62/2.44 48/1.89
CFC-100 / CFHD-100-60S / CF2-100-0015 / CF1-100-0015 100 +/-5% 15.0 9 80 62.3/2.45 44.5/1.75
VC1C-100-0015 / CF3-100-0015 / MC1C 100E 100 +/-5% 15.0 9 54 62/2.44 48/1.89
CKT1-100-0025 100 +/-5% 25.0 15 70 114/4.5 68/2.68
VC2C-100 / MC2C 100E 100 +/-5% 30/25/20 18/15/12 128 73/2.87 48/1.89
CKT-100-0035 / CF2C-100F 100 +/-5% 35.0 25 87 165.1/6.5 58.9/2.32
CF2-120-0010 / CF1-120-0010 120 +/-5% 10.0 6 71 62.3/2.45 44.5/1.75
VC1C-120-0015M / C1C 120E 120 +/-5% 15.0 9 70 62/2.44 48/1.89
CFHD-125-60S
VC1C-130-0015M / C1C 130E 130 +/-5% 15.0 9 83 62/2.44 48/1.89
CF2-147-0010 / CF1-147-0010 147 +/-5% 10.0 6 75 62.3/2.45 44.5/1.75
CF2-150-0010 / CF1-150-0010 150 +/-5% 10.0 6 75 62.3/2.45 44.5/1.75
VC1C-150-0015M / C1C 150E 150 +/-5% 15.0 9 96 62/2.44 48/1.89
VC2C-150 / MC2C 150E 150 +/-5% 30/25/20 18/15/12 83 73/2.87 48/1.89
CKT-150-0030 / CF2C-150E 150 +/-5% 30.0 20 90 165.1/6.5 67.5/2.66
CFC-175
CF2-180-0010 / CF1-180-0010 180 +/-5% 10.0 6 100 62.3/2.45 44.5/1.75
VC1C-180-0015M / C1C 180E 180 +/-5% 15.0 9 100 62/2.44 48/1.89
CKT-200-0030 / CF2C-200F 200 +/-5% 30.0 20 95 165.1/6.5 67.5/2.66
CFHD-200-60S / CFC-200-15S
CF2-200-0009 / CF1-200-0009 200 +/-5% 9.0 5.4 75 62.3/2.45 44.5/1.75
VC1C-200-0015M / C1C 200E 200 +/-5% 15.0 9 104 62/2.44 48/1.89
CF2-210-0009 / CF1-210-0009 210 +/-5% 9.0 5.4 76 62.3/2.45 44.5/1.75
VC1C-210-0015M / C1C 210E 210 +/-5% 15.0 9 107 62/2.44 48/1.89
CKT-250-0030 / CF2C-250F 250 +/-5% 30.0 20 100 165.1/6.5 67.5/2.66
CFED-300-25S / CFC-350
CFED-400-25S / CFHP-450-55S 450 +/-5% 55.0 33 500 139.7/5.5 142.75/5.62
CFC-500 / CFED-500-40S / CFHP-500-55S / CFFP-500-40S / CFED-500-25S 500 +/-5% 25.0 15 200 96.77/3.81 115.82/4.56
CFC-600 / CFC-750
CFHP-750-0040 / CFHP-750-0045 / CFHP-750-0050 750 +/-5% 50.0 30 340 130.1/5.12 182.90/7.2
CFED-750-10S / CFED-750-15S / CFED-750-20S / CFED-750-25S 750 +/-5% 25.0 15 200 96.77/3.81 115.82/4.56
CFDP-1000-15S / CFHP-1000-40S / CFHP-1000-45S / CFHP-1000-50S 1000 +/-5% 50.0 30 360 157.48/6.20 182.90/7.2
CFED-1000-10S / CFED-1000-15S / CFED-1000-20S / CFED-1000-25S / CF1C-1000H 1000 +/-5% 25.0 15 230 96.77/3.81 115.82/4.56
CFC-1000 / CKT1000/35/210 1000 50.0 35 210 185/7.28 200/7.87
CFDP-1500-15S 1500 +/-5% 15.0 9 190 83.82/3.31 42.75/5.62
CFFP-1500-25S / CFFP-1500-30S / CFFP-1500-35S 1500 +/-5% 35.0 21 350 146.80/5.78 208.3/8.2
CFED-1500-25S
CFDP-2000-7.5S / CFDP-2000-10S / CFDP-2000-15S / CF1C-2000F/15 2000 +/-5% 15.0 9 200 83.82/3.31 42.75/5.62
CFFP-2000-35S 2000 +/-5% 35.0 21 350 146.80/5.78 208.3/8.2
CFHM-2000-0040 / CF2C-2000E/40 2000 +/-5% 40.0 24 400 153.4/6.04 208.28/8.2
CKT2000/30/400 2000 42.0 30 400 250/9.84 185/7.28
CFFM-2500-30S 2500 30
